Quick Details

Place of Origin: Cambodia                         Brand Name: AL-MARTCAMBODIA              Model Number: 1.22x2.44m

Usage: Outdoor                                    Function: Fireproof                                Surface Treatment: Anodized,PE Coated

Packaging & Delivery

Specifications

composite panel
1. Front side: aluminum plate coated with PVDF or polyester
2. Core: plastic fireproof materials


composite panel

Aluminium-plastic composite board is a high-tech product with steady quality, outstanding characters,low cost and extensive uses.It is manufactured by the Chungkong AD-MART.
Aluminium-plastic composite board is made of the aluminium board and the polyethylene.Its surfaces painted with fluorocarbonresin look noble,elegant,beautiful and colourful.It provides abundant room for the modern building design.It is a new decorated material for the new style wall,and represents the developing tendency of the international wall system.
Aluminium-plastic board is accompanying with human being’s civilization, and expounding the quintessence of the era.

Scope:
Building’s wall curtain,decoration of the new or old build,notice board,advertisement board,exhibiting shell,decoration of the shop,ceiling,furniture,industrial material,bodywork,hull,decoration of the machine’s surface,wall of the tunnel,etc.

Structure:
aluminium-plastic board is mainly made of 6 parts,and divided into 14 layers in detail.
A.producing layer
B.surface painted aluminium board
C.macromolecular adhesive
D.polyethylene middle material
E.macromolecular adhesive
F.back protecting aluminium board

Product specification:
1.Standard specification Length:2440mm/width:1220mm/Thickness:3mm
2.Non-standard specification Length:to 6000mm/width:to 1550mm
3.Varied specifications and colours can be booked according to the needs of the customers.

Advantages:
1.Light in weight
2.Low cost of production
3.Rich in colour and feel
4.Good in plastic

Colour Illustration:
Those colours are just for refrence,please take the true colours of the practicality as standard.

Characteristic:

A.Super adhesive firmness:
Aluminium-plastic board adopts imported macromolecular adhesive membranes and international high-new techniques,so its firmness is very strong.After the eight-hour experiment in the boiling water,the adhesive layer has nothing broken.And after the aging experiment according to the ASTMC481CYCLeB,its stripping intensity is >=8N/mm.Aluminium-plastic board won’t be stripped in a long term use because of the super stripping intensity.

B.outstanding climate-resistance and temperature-adaptability:
The surfaces of aluminium-plastic board adopt the imported America LILLY and Swedish Becker fluorocarbon resin paint.The adhesion of the paint coat is very good.And this makes the surfaces very wear-resistant,acid-resistant,alkali-resistant and salt-fog-resistant.The biggest advantage of the fluorocarbon resin is its good climate-resistance.The paint membrane’life can reach 15 to 20 years generally,and it will be used chronically without fading and stripping. The board performs very

C.fireproof:
Aluminium-plastic board is fireproof remarkably.Adopting polyethylene and frame retardants(AL2O3.3hH2O and mg(OH)2 in high degree of purity),the middle is shaped by pressure at a high temperature.It is non-poisonous and fireproof,confirming to the fire-resistant demand of the building rule completely.

D.light in weight and easy to process:
Aluminium-plastic board is light in weight and easy to process.Its core board is of low density, high intensity and high toughness.Because of the board’s light weight,it will reduce the damage in earthquakes and be transported easily.Besides,the board is very easy to process.It can be folded,cut,milled,and curved just with the process tools of the carpentry factories or the metalworking factories.So the cost of the project will be reduced.

E.sound-insulation and heat-insulation:
Aluminium-plastic board is made up of several layers.The middle adopts a special craft structure,so the product is good in sound insulation and heat-insulation.

F.impact-resistance:
Aluminium-plastic board is very impact-resistant and tough.The paint coat won’t be broken when the board is distorted with a strong force.In the windy and dusty environment,the board won’t be broken by the wind and the sand because of its good wind-resistance and compressive insistence.

G.various colours:
Aluminium-plastic board is rich in colour style.Having 32 standard colour systems,it provides many selections for customers.It can also be adjusted for the needs of the customers,and satisfy the varied designs of the architects.

H.easy to maintain and clean:
Aluminium-plastic board is a new material not easy to be dirtied.But because of the different environments,it may be dirtied.At the moment,it needs to clean.Water or neutral detergent will be ok.If some detrimental gases and ingredients can’t be cleaned by water or neutral detergent,please wash with lotion or organic detergent.Then the board will become as a new one.
